Unit details
ORDER YOUR’S 2025 FRONTIER TODAY! Standard Features
STOCK LOWPRO 7X20 DDFW BP
12′, 14′, 16′ & 20′ Floor; 7′ Wide; 6′ Tall
V-Nose Bumper Pull w/24″ Stone Guard
All Box Tube Aluminum Chassis
One Piece .040″ Aluminum Roof w/Heavy Duty Radius Roof Extrusion
Extruded Aluminum Decking; 12″ O/C I-Beam Crossmembers
.040″ Pre-Painted Exterior Side Sheets & Lower Extruded Aluminum Sides
Tandem 3.5K Braked, Dexter Torsion Ride Axles
4 Wheel Electric Brakes w/Safety Break-Away Kit
All LED Exterior Lighting
Newly Designed 4′ Adjustable Stalls w/Spring Latch Systm (8)
Tack Area: 44″ Tack; 32″x64″ Tack Access Door w/Sliding Window & Screen; 1/2″ Rubber Mats; (1) LED Dome Light w/Wall Switch
Aluminum Rim 225/75R15 6-Lug Wheels
Heavy Duty Rear Step-Up Rubber Bumper
45″x18″ Drop Down Feed Window (Per Stall)
(1) Air Gap w/Flip-Down Cover
Full-Length Running Boards
50/50 Double Rear Doors w/Sliding Windows & Bars
Full-Length LED Strip Lights in Stock Area (Both Sides)
Manual Landing Gear
Escape Door Pen Gate; U-Bolt Spring Latches for Pen Gate Tie-Backs
36″x64″ Escape Door w/Locking Bar & 30″x24″ Drop Down Feed Window
Double Action Pop-Up Vent (Per Stall) Additional Options
STOCK LOWPRO 7X20 DDFW BP
Stainless Steel Nose Wrap – Mirror Finish (Nose Cone)
6″ Extended Tongue (Includes Center Upgrade)
Upgrade to 2-5K Torsion Braked Axles (From 2-3K Braked)
Upgrade to Black Aluminum Rims from Aluminum (Same Size)
Upgrade to 16″ Aluminum Wheels (Radial; From 15″ 225 Aluminum)
Add 3″ to Box Height (PBF)
Ramp Over Double Doors
Access Door to Tack Area 20″ x 64″ (Interior)
Upgrade to 45″x24″ Drop Down Feed Window (Premium, Integrated Bars) from 45″x18″ Drop Down Feed Window
12V LED Load Light (Single Light w/ Switch, 950 Lumen)
110V Power Package #2 (1) 30 Amp Breaker w/ 25′ Shore Line, (2) Standard Wall Receptacle & (2) GFI Wall Receptacle
Brace and Stub Wire for Future AC Installation
.030 Ceiling Liner w/ Insulation (Tack Area)
.030 Wall Liner w/ Insulation (Tack Area)
.030 Ceiling Liner w/ Insulation (Horse Area; PLF)
.030 Wall Liner w/ Insulation Above HD Liner (Horse Area; PLF)
Bucket Hangers (Stock Area) (per Pen Gate)
Bucket Hangers (Tack Room) (Set of 6)
36″x18″ Hat Shelf for LowPro w/ Clothing Rod
Upgrade Rear Ramp to Stainless Steel Skin
Add 36″ Wide Ramp on Side of Trailer (DDFW models only)
Floor-Level Spare Tire Mount
Spare 15″ Silver Mod Wheel w/ 225/75R15 Wheel
Spare 16″ Silver Mod Wheel w/ 235/80R16 Wheel
Powdercoat LowPro Pen Gate (EA)
